Product Advantages

Small Area Required
Only 0.4 Square Meters of Space Required.Can be Flexibly Placed at Checkout or Kitchen Areas.

Small Area Required
Only 0.4 Square Meters of Space Required.Can be Flexibly Placed at Checkout or Kitchen Areas.

Rich Functions
Can Handle 17 Types of Various Juices/Milk/Sugars with Different Viscosities.

Rich Functions
Can Handle 17 Types of Various Juices/Milk/Sugars with Different Viscosities.

One-Button Cleaning
Automatic Cleaning Function.Fully Unattended Operation.
More Worry-Free, Convenient, and Efficient.

One-Button Cleaning
Automatic Cleaning Function.Fully Unattended Operation.
More Worry-Free, Convenient, and Efficient.

Full Pipeline Refrigeration
Liquid Temperature Controlled Below 8℃.Ensured Fresh and Safe Ingredients.More Reliable Food Safety.

Full Pipeline Refrigeration
Liquid Temperature Controlled Below 8℃.Ensured Fresh and Safe Ingredients.More Reliable Food Safety.
Product Parameters

Product model
Model K (NCJ-K)
Product dimensions
660×540×1550mm
Product power
1.2kW/220V 50HZ or 110V 60HZ
Net product weight
Approximately 165 KG
Screen Size
10.1 Inch
Operating Syste
Android 7.1
Discharge Method
Discharge by QR Code Scanning
Cooling Method
Air Cooling
Portion Box
2
Automatic Discharge
17 Types (Customizable)
Refrigeration
7*3.5L + 5*2.5L +External Tea Bucket 3*8L +
Heating Syrup Machine 1*3.5L (Expandable by 2 Units)
Accuracy Calibration
±1-3ml
Discharge Speed
5-8 seconds
End-of-Day Cleaning
CIP Cleaning
Output Ingredients
Tea, Syrup, Milk, Juice, Thick Fruit Puree, etc.
Cooling Temperature
Full Pipeline Refrigeration
Output Materials


Tea


Tea


Syrup


Syrup


Milk


Milk


Juice


Juice


Puree


Puree
Application Scenario
Large Stores with High Automation
Requirements

Fresh fruit milk tea

Bubble Tea

Meat fiber milk tea

Jam milk tea
Product Recommendation
Software System

Device backend management system
Flexible and elastic product design that can cater to different types of tea drinks; Provide solutions that are closer to your needs.

Milk Tea Machine Operating System
Scan the code to dispense tea, quickly dispense ingredients, one click cleaning, and complete functions; Simple operation interface and fast response speed.
Application Cases
